Road Line Marking Machine | High-Precision Road Striping
🎯 High-Precision Casting System
Engineered with a specialized high-precision cast iron bucket to ensure sharp edges, uniform thickness, and perfect linear appearance.
✨ Automatic Glass Bead Dispenser
Equipped with a speed-controlled buffer device for even, full-coverage glass bead spreading, maximizing nighttime visibility and safety.
🔄 Agile Curve Maneuverability
Features a manual shift mechanism for effortless curve marking, providing high-quality results on both straight roads and complex turns.
⚡ Rapid & Low-Maintenance Operation
Designed for fast construction and flexible handling, with a modular structure that ensures convenient maintenance and long-term reliability.
Heating Marking Liner Features
Hand crossed Road Line Marking Machines are the key to construction equipment, used in conjunction with hot melt kettle, marking the completion of construction, manufacture of aircraft using special high-precision cast iron bucket line to ensure that the marking is zoned side on the first homogeneous, uniform thickness, linear appearance, landing knife can adapt to different situations of the road surface, glass beads spread complete with automatic speed control buffer devices, devices can be manually shifted curve achieve excellent construction, concrete marking, high-quality construction, construction fast, flexible operation, convenient maintenance and so on.
| Technical Parameters | |
| Type | CK380S |
| Engine | Double stainless steel insulate container,it plugged-in manually device，which can be removed.Material container volume is 100kg |
| Glass Beads Container Volume | 10kg |
| Adjustable Glass Beads Dispenser | Glass beads dispenser fordispensing glass beads synchronously and quantitatively.It makes the dispensing synchronization with the marking line and ensures the quantity of the dispensing is controllable aand adjustable.The dispense width of this dispenser is adjustable:from 50mm to 200mm. |
| Marking Mold | High precision ultra-thin material,unique design of screed box bottom ,ensures a good sealing and easy open & close |
| Tire | Alloy Wheel,a special heat-resistant rubber.It also has rear wheel directional steering device to ensure the machine moving in straight line or turning freely. |
| Heating device | Using seamless steel material tube.It perfectly prevents air leak |
| Heating device | 50/100/150/200/250/350/400/450 mm(optional) |
| Battery Capacity | 15AH |
| Battery Voltage | 48V Lithium battery |
| Driver Speed | 1-8km/hour |
| Working Duration | Machine can mark road lines24 hours after chargingbattery5 hours |
| Dimension | 1220X920X1100mm |
| Weight | 150kg |
| Brake | Using drum brake,you can adjust the brake tension |
